One device built in dual lens,one for DMS (driver monitoring system) camera, the other for road facing camera. Both AHD 1080P resolution.
Brand:
DUUHNNItem NO.:
DH-RC40Order(MOQ):
1pcsPayment:
TT, Paypal,Western Union,MoneyGram,AlipayPrice:
Warranty:
2YearsDelivery Time:
3-8 working days for sampleshare to:
Highlight
One device built in dual lens,one for DMS (driver monitoring system) camera, the other for road facing camera. Both AHD 1080P resolution.
Technical Parameter
| Sensor | 1/2.9” CMOS AHD(FH8536H+GC2053 | 1/2.9” CMOS AHD(FH8536H+GC2053(optional) |
| 1/4.5” CMOS AHD(FH8535L+GC1084) (optional) | ||
| Duel Lens Camera | Road Facing Camera | DMS Camera(Driver Monitoring Cam) |
| TV Standard | PAL/NTSC | |
| Resolution | 1920*1080(2.0Mp) | |
| Synchronization system | internal synchronization | |
| Minimum illumination | 0.1Lux/F1.2 | |
| Video output | 1.0vp-p，75Ω | |
| Electronic shutter | AUTO/ 1/50(1/60)-1/100,000sec | |
| AGC | Auto | |
| Sound to Noise Ratio | > 48dB | |
| White balance | Auto | |
| BLC | Auto | |
| lens Size | 6mm F=2.0 | 3.6mm F=2.0 |
| Lens horizontal angle | 55° | 80° |
| Lens Diagonal angle | 72° | 100° |
| IR distance | 2-3Meters | |
| IR-CUT | Support | |
| Audio | Support | |
| Current and voltage | 120mA-200mA ± 10% (when the infrared light is turned on, the IR-CUT switching moment reaches 350mA) | |
| Operating temperature | DC9-16V ±10% | |
| Storage temperature | -20°C~70°C, RH95% MAX30°c~80°C, RH95% MAX | |
| Net Weight | 120g (without cable) | |
